Reinforcing bars are cut at pipe penetrations with additional lapping bars added to match structural requirements. Tension lap splices are used alongside fifteen-millimeter bottom bars spaced at four hundred millimeters or one foot four inches. A minimum of seventy-five millimeters or three inches of concrete cover is maintained. Bars are hooked where the footing cannot accommodate straight bar embedment.
LAP TENSION CUT BARS AT PIPE. RUN ADDITIONAL LAPPING BAR TO MATCH. MIN 75 (3") 15M @ 400 (1' - 4") 15M @ 400 (1' - 4") BOT. COVER 75 (3") 4 0 400 (1' - 4") OR HOOK WHERE FOOTING CANNOT ACCOMODATE STRAIGHT BAR EMBEDMENT 1 1
