Insulated metal panel connection to steel framing member. Steel member positioned against panel, with backer rod installed at interface where required. Joint sealed with caulk applied along entire length of member, per caulking schedule on sheet A2.1. Metal framing member size determined per structural drawings.
Text on the drawing
BACKER ROD, WHERE REQUIRED MTL. FRAMING PER PLAN, REFER TO STRUCTURAL INSULATED MTL. PANEL PER PLAN CAULK ENTIRE LENGTH OF MEMBER, SEE CAULKING SCHEDULE ON SHEEET A2.1
