A concrete sump pit recessed below the slab on grade features eight-inch typical concrete walls and base reinforced with four number four bars each way. The pit opening is framed with a one-and-a-half by one-and-a-half by three-sixteenths angle embedded with two half-inch diameter by three-inch studs on all four sides. A W-nineteen-fourteen one-and-a-quarter by one-eighth galvanized grating sits flush within the frame opening unless noted otherwise.
2' - 0" 2' - 0" 8" TYP (4) #4x EW L1 1/2x1 1/2x3/16 W/ (2) 1/2" DIA x 3" STUDS, TYP (4) SIDES W-19-14 (1 1/4X1/8) GALV GRATING, UNO SOG, SEE PLAN 1'-0" 1'-0" 10 TYPICAL SUMP PIT
