This structural section details the concrete slab and tunnel configuration for a paint booth, with a top of main floor elevation reference line. The assembly incorporates a concrete base slab with a thickness of one hundred and fifty millimeters, reinforced with steel rebar and supported by foundation elements. A continuous waterproofing membrane and insulation layer are specified per architectural drawings along the exterior of the tunnel structure. Vertical and horizontal concrete dimensions include a vertical drop of eleven hundred sixty-five millimeters and a base section height of six hundred fifty millimeters.
T.O MAIN FLOOR 1165 650 100 INSULATION SEE ARCH, TYP WATERPROOF MEMBRANE SEE ARCH, TYP 150
