A steel beam sized per plan connects to a concrete masonry unit wall using a special single plate beam connection type C. The connection utilizes a vertical plate anchored into the masonry wall with bolts securing the beam web. Above the beam, a roof deck and edge detail are specified per plan.
SEP-1 RF DK PER PLAN ED-1 SPECIAL SINGLE PL BM CONN TYPE C CMU WALL PER PLAN BM PER PLAN
