Openings spaced three times dimension D on center or more shall be reinforced as individual openings per the reinforcement table based on the largest opening. Openings spaced closer than three times dimension D require special detailing as a combined opening.
OPNG'S SPACED 3xD oc OR MORE SHALL BE REINFORCED AS INDIVIDUAL OPNG'S PER TABLE D D D ON LARGEST OPNG.) 3xD oc MIN. (BASED
