A hollow structural section brace connects to a half-inch thick gusset plate. The gusset plate is welded to the supporting structural assembly with a five-sixteenth-inch fillet weld. A working point is established at the intersection of the framing lines.
HSS BRACE 5 1'-6" 6" 1 1/2" 1 1/2" 1 1/2" GUSSET PLATE 1/2" 5/16 4 W.P. HSS BRACE SEE PLAN
