A continuous 600T150-54 cold-formed steel stud track is anchored to the roof deck with two number 10 screws at each high flute. Cold-formed steel studs are secured to the continuous track with a number 10 screw at each flange on each stud. The roof deck bears on a wide-flange beam sized per plan.
3" CONT. 600T150-54 w/ #10 SCREW EACH FLANGE AT EACH STUD EL. SEE PLAN (2) #10 SCREWS AT EACH HIGH FLUTE ROOF DECK WF BEAM SEE PLAN
