An angle brace connects to a wide flange beam where required, supplemented by an L6x4 angle depending on the beam depth. The assembly interfaces with a wall featuring a drift track connection designed to allow vertical building deflection and seismic drifts as noted on the general structural notes. A ceiling reference is coordinated per architectural drawings.
ANGLE BRACE, WHERE OCCURS WIDE FLANGE BEAM 6" ± CEILING SEE ARCH SEE ARCH L6x4 IF REQ'D BY BEAM DEPTH DRIFT TRACK CONNECTION TO ALLOW VERTICAL BUILDING DEFLECTION AND SEISMIC DRIFTS NOTED ON THE GSN
