Reinforcing column ties and beam stirrups feature standard and ductile hook configurations with 135-degree and 90-degree bends. Dimension "a" for ties number 5 and smaller equals six bar diameters with a three-inch minimum, and equals six bar diameters for number 6 through number 8 ties. Dimension "b" for ties number 5 and smaller equals six bar diameters with a three-inch minimum, and equals twelve bar diameters for number 6 through number 8 ties. Alternate positions for successive tie splices and bend locations are provided for seismic detailing.
TYPICAL COLUMN TIES BEAM STIRRUPS DIMENSION "a" FOR #5 TIES & SMALLER = 6d b , 3" MIN FOR #6-#8 TIES = 6d b DIMENSION "b" FOR #5 TIES & SMALLER = 6d b , 3" MIN FOR #6-#8 TIES = 12d b DUCTILE ALTERNATE POSITION OF SUCCESSIVE TIE SPLICES TYPICAL OPTIONAL ALTERNATE POSITION OF 135° AND 90° BENDS TYPICAL 1 1 1 1 "a" "a" "a" "a" "a" "b" "a" 1A 1B STANDARD STANDARD
