An existing concrete shear wall meets a structural slab at Level 1, established at elevation twelve feet four and one-half inches. A three-inch existing expansion joint accommodates movement at the building interface. Modifications to the existing structure at the interface are governed by the adjacent 200 Mission drawings.
245 LEVEL 1 12'-4 1/2" 200 MISSION (E) CONC SW (E) 3" EXP JT, FV REFER TO 200 MISSION DWGS FOR MODIFICATIONS TO (E) STRUCT AT INTERFACE
