This structural detail shows a cast-in-place concrete grade beam with top, bottom, and side reinforcing steel configured per the structural schedule. Two number four dowels spaced at sixteen inches on center extend twelve inches into the grade beam to anchor the slab. Number five bars are included on each face when the beam depth exceeds thirty inches. Stirrups enclose the longitudinal reinforcement at spacings defined in the schedule. The finish grade is shown above the slab assembly, with beam depth and width sized per schedule.
NOTE: SEE SCHEDULE FOR ADDITIONAL INFORMATION. EXTEND REINFORCING INTO ADJACENT FTG PER TYPICAL GRADE BEAM REINFORCEMENT" DETAIL. FINISH GRADE SEE SCHED DEPTH PLAN SEE SEE SCHED WIDTH (2)#4 DOWEL @ 16"OC W/ 12" EMBED INTO GB STIRRUPS SEE SCHED TOP (T) BAR BOT (B) BAR TOP ADDED (TA) BAR BOT ADDED (BA) BAR #5 EF (FOR DEPTH GREATERTHAN 30")
