Composite plate shear wall connection configurations feature boundary plates with six-inch diameter concrete flow holes spaced at twenty-four inches on center. Intermittent alignment plates are provided by the contractor at panel joints and splices. Complete joint penetration welds and five-sixteenth inch fillet welds secure the steel plate assemblies.
SPLICE, SEE "TYP PANEL TO PANEL CONN", TYP CJP INTERMITTENT ALIGNMENT PL, TYP, BY CONTR PLAN CJP 5/16 5/16 6" DIA CONC FLOW HOLES IN BOUNDARY PLATE AT 24" OC Drawn By: Sheet Number: © 2019 Solomon Cordwell Buenz TYPICAL COMPOSITE PLATE SHEAR WALL DETAILS OAKLAND, CA 94612 2200 TELEGRAPH AVE.
