A gusset plate assembly connects to a horizontal base plate with a ninety-degree work point located at the top of the base plate. One-half-inch thick stiffener plates are welded to both sides of the gusset. Five-sixteenths inch fillet welds secure the connection, with additional weld sizes and lengths designated by variables such as W sub b and L sub b. Bolt hole patterns are arranged symmetrically on the gusset plates for structural framing attachment.
L gb APPROX TYP L gc APPROX 5 SEE TYP W b 6 TYP, SEE 90° W.P. @ TOP OF BASE PLATE BASE PLATE 12 " STIFF BOTH SIDES OF GUSSET 516 L wb
