A two-inch expansion joint with waterstop is detailed at the vertical transition of a concrete slab. The stepped concrete slab features a sloped transition region with a three-to-one slope and varying elevations from minus one foot six inches to minus nine feet two inches. A PVC liner is provided as shown on plan, and slab reinforcement is detailed per referenced structural drawings.
SEE SECTION C/000-C-08-3001 FOR SLAB REINF SEE DETAIL 2/020-S-55-5001 PVC LINER, SEE PLAN (TYP) 2" EXP JT W/WSTP (TYP) TYP S130 3 1 2'-0" 1'-6" 1'-6" 2'-0" EL -1.50 EL -9.25 EL -2.25
