A hollow structural section diagonal brace connects to a three-quarter-inch gusset plate welded beneath a steel beam per plan and an HSS column per elevation. The diagonal HSS member is welded with a three-eighths-inch fillet weld, maintaining a minimum length of ten inches, and includes a working point offset designated as two times the thickness. The gusset plate meets the beam and column joints at the specified working point, with minimum six-inch weld lengths.
CL TUBE TYP. TYP. L=10" MIN, WP L=6 MIN. GUSSET PLATE 3/4" CL TUBE 2T PER ELEVATION PER ELEVATION HSS. PER ELEV. HSS. PER ELEV. STEEL BEAM PER PLAN 3/8 3/8
