Fastener attachment patterns for a three-foot wide metal roof deck sheet. Fasteners are installed along perimeter supports parallel to the deck span according to specific spacing requirements. Patterns 36/9 through 36/11 require a maximum spacing of four inches on center, while patterns 36/4 through 36/7 require a maximum spacing of six inches on center. Refer to the roof framing plans to determine the specific attachment pattern and fastener type required for the project.
Text on the drawing
3'-0"SHEET WIDTH NOTES: 1. REFER TO ROOF FRAMING PLANS FOR ATTACHMENT PATTERN AND FASTENER TYPE 2. ATTACH TO PERIMETER SUPPORTS PARALLEL TO DECK SPAN: 36/9 to 36/11 - @ 4" O.C. MAX 36/4 to 36/7 - @ 6" O.C. MAX FASTENER 36/7 PATTERN 36/9 PATTERN 36/5 PATTERN 36/4 PATTERN 36/11 PATTERN
