A steel beam supports a steel deck per plan with a coped top flange as needed. A quarter-inch by three-inch plate measuring zero feet four inches long connects the assembly using three-sixteenth-inch fillet welds. A depressed steel beam detail features an angle measuring two and a half by two and a half by a quarter-inch by zero feet three inches long at the joist seat depth. Three-sixteenth-inch fillet welds secure the connection components as indicated on the drawing.
T/STL 3/16 3/16 3/16 3/16 3/16 L2-1/2x2-1/2x1/4x0'-3" STEEL DECK PER PLAN C3 (C4 AT SIM) PL1/4x3x0'-4" DEPTH JOIST SEAT COPE TOP FLANGE AS NEEDED STEEL BEAM DEPRESSED STEEL BEAM RO RO 3/16 3/16 (4" AT SIM) 3" BEAM PER PLAN BEAM PER PLAN
