The assembly connects framing beams to an existing structural steel column using four typical 16 gauge L-shaped plates. Each plate is secured to the beam flange with a one-quarter inch minimum fillet weld. Twelve number ten self-tapping sheet metal screws fasten the strap end to the sixteen gauge plate at one inch on center spacing typical. The configuration repeats across four sides of the column with a typical dimension of twenty-four inches.
12 - TYP. BM. CONN. TO (E) COL. (12) #10 SMS FROM STRAP END TO 16 GA PLATE, 1" O.C. SPCG, TYP. 1/4 MIN. TYP. PLATE TO BM FLANGE 16 GA X REQ'D L-SHAPED PLATE, TYP. OF 4 +/- 24" TYP.
