A top deflection track mounts beneath the supporting structure above with a gap indicated by a dimension of three-quarters of an inch. The track web contains one-quarter-inch by four-inch slots staggered at six inches on center. Anchors fasten through the slotted web according to the project schedule requirements.
BOT OF SUPPORTING STRUCTURE ABOVE TOP DEFLECTION TRACK PER SCHEDULE (SHOWN AS BOTTOM TRACK FOR SIMPLICITY) 1/4" X 4" WEB SLOTS STAGGERED @ 6" OC SEE SCHEDULE FOR ANCHOR & SPACING REQUIREMENT 3/4"
