A buckling-restrained braced frame connection features a V-shaped gusset plate assembly anchored to a base plate. CoreBrace buckling-restrained braces connect via gusset plates with specified bolt diameters, edge distances, and weld sizes. Half-inch stiffener plates reinforce both sides of the gusset plate above the base plate. The base plate rests on a concrete foundation with a concrete block-out at the surrounding slab on grade.
17.1504 W b Lwb TYP TYP 5/16 STIFF PL AS REQ'D BY COREBRACE, TYP GUSSET THICKNESS, tg WORK POINT @ TOP OF BASEPLATE CONCRETE BLOCK OUT SLAB ON GRADE CONCRETE FOUNDATION 1/2" STIFF BOTH SIDE OF GUSSET COREBRACE BRB,TYP BOLT DIAMETER, db Lgc Lgb TYP
