An angle brace connects to a steel beam running parallel to the metal deck above, utilizing angle sizes determined by the brace length such as L4x4x3/8 for lengths under six feet and L6x6x3/8 for lengths between six and ten feet. A three-eighths-inch plate may be field welded to the beams at the contractor's option. The top connection to the beam is similar to the connection at the bottom of the beam.
DECK PARALLEL TO BEAM 1. 3/8" PLATE MAY BE FIELD WELDED TO BEAMS AT CONTRACTORS OPTION. 2. SEE FRAMING PLAN FOR BRACE LOCATIONS SHOWN ON PLAN THUS: 3. UNO ON PLANS, ANGLE BRACE SHALL BE: L4x4x3/8 FOR "L" < 6'-0" L6x6x3/8 FOR "L" > 6'-0" < 10'-0" TOP CONN TO BEAM SIM TO CONN AT BOTTOM OF BEAM 17 TYP BEAM LATERAL BRACE DETAIL
