Steel beams frame into the column web at differing depths using a bolted shear tab and top and bottom continuity plates. The shear plate thickness equals the beam web thickness plus one-quarter inch. Continuity plates match specified top and bottom flange sizes, welded with fillet welds typical unless noted otherwise. A second row of bolts is added as required per structural plans. Edge distances and bolt spacings follow AISC specifications.
BEAM TO COLUMN WEB CONNECTION A (DIFFERENT BEAM DEPTH) FOR EDGE DISTANCE AND BOLT SPACING SEE AISC SPECIF, TYP SHOWN ON PLAN THUS: No & SIZE OF BOLTS (SEE NOTE 3) 2ND ROW OF BOLTS AS REQUIRED, SEE PLAN TO STEEL CONTINUITY PLATE T&B (SEE DETAIL "E") SHEAR TAB THICKNESS = BEAM WEB THICKNESS + 1/4" IF LESS THAN 3" OMIT CONT PLATE THIS SIDE * SEE SCHED TF2 TF1 3" MIN TYP 2" TF1 TF2 TF1 TF2 CP T&B FLANGES, TYP UNO M *
