A wide flange beam connects to another wide flange beam using a WT shape with a three-inch at twelve-inch weld pattern. A one-quarter-inch stiffener plate is placed on each side at four feet zero inches, spaced six inches from each end of the WT. Welds connect the WT to the beam with a three-sixteenths fillet weld size.
BEAM TO BEAM WT TO BEAM WF BEAM SEE PLAN WF BEAM SEE PLAN BEAM SEE PLAN TO STEEL SEE PLAN 1/4" STIFF PL EACH SIDE @ 4'-0" 6" FROM EACH END OF WT TO STEEL SEE PLAN WT SEE PLAN 3/16 3/16 WT TO BEAM 1/4 3@12 TOP OF CONC FACE OF ELEVATOR PIT HSS6x4 SEPARATOR BEAM L8x6x1/2 (LLV) 1/2" EMBED PLATE 2-3/4"Ø WELDED STUDS AT ELEVATOR PIT WALL A 2" 4" 6" 6" 1 1/2" 4 1/2" 4 1/2" 1 1/2" 4 1/2" 4 1/2" 3/16 1/4 3 MIN HSS TO ANGLE NTS 2 WF BEAM SPLICE CONNECTION (NON-MOMENT)
