A steel beam supports a concrete over metal floor deck and connects to a concrete tilt-up wall panel. Horizontal long slotted holes are provided in the beam web at the connection. A separate condition presents the steel beam framing into a concrete lintel or coupling beam above a glazed opening.
STL BM CONC TILT-UP PANEL, SEE SCHEDS AND ELS HORIZ LONG SLOTTED HOLES IN BM WEB CONC OVER MTL FLR DECK S801 3 AT CONDITION WHERE BEAM RESTS WITHIN 12" OF A PANEL JOINT, SEE / (1 S610) S801 3 CONDITION AT SOLID WALL CONDITION AT OPENING GLAZING, SEE ARCH. TYP CONCRETE LINTEL OR COUPLING BEAM, SEE ELEVATIONS STL BEAM CONC OVER MTL FLR DECK
