Steel beams frame into opposite sides of a continuous hollow structural section column using shear tab plates welded to the tube face. A plate extends through a kerf cut into the column tube on one side, while the opposite side features a shear tab welded directly to the hollow structural section face with quarter-inch fillet welds at the tube corners without requiring a kerf. High-strength bolts secure the beam webs to the connection plates.
NOTES: 1. WELD PLATE TO HSS FACE AT TUBE CORNERS; NO KERF REQUIRED. REFER TO TYPICAL SHEAR TAB CONN DETAIL FOR INFORMATION NOT SHOWN, TYP HSS COL 1/4 1/4 PER TYP SHEAR TAB CONN DETAIL BM PER PLAN KERF TUBE & EXTEND PL THRU COL (SEE NOTES) DRAWN BY: PM: DATE DESCRIPTION © MG2,Inc.All rights reserved. No part of this document may be reproduced in any form or by any means without permission in writing from MG2, Inc. STRUCTURAL STEEL DETAILS 07/26/2023 DG 21-165-01 CM
