A spreader beam connection frames into a hollow structural section column using plates on each side. Two three-quarter-inch-diameter through-bolts pass through horizontal short slotted holes in the connection plates to allow movement, maintaining a maximum one-half-inch gap at the column face. A one-quarter-inch plate welded with typical three-sixteenth-inch fillet welds secures the HSS beam per plan. The assembly accommodates standard structural steel framing dimensions with specific clearances indicated.
T/STL PER PLAN AT COLUMN MAX 1/2" GAP SECTION 1" PL 1/4x4x0'-6" EA SIDE W/ (2) 3/4"Ø THRU BOLTS IN HORIZ SHORT SLOTTED HOLES COL PER PLAN 3/16 3/16 TYP HSS BEAM PER PLAN SECTION 3" TYP 1 1/2" PL1/4, TYP THRU BOLTS, TYP HSS PER PLAN 1 1/2" BIM 360://PresidioBayVentures - 200 Kansas/Struct-19081-0118-R2020.rvt
