A structural column cross-section details a central hollow structural section column surrounded by six number six vertical reinforcing bars with number three ties spaced at six inches on center. Adjacent ties maintain a six-inch minimum stagger overlap. Vertical reinforcing bars terminate with standard hooks typically. A three-inch concrete clear cover is maintained to the outside face.
6-#6 VERT W/ #3 TIES @ 6" O.C. B CLR. 3" @ ADJACENT TIES 6" MIN. STAGGER OVERLAPS HSS COL., S.P. TERMINATE W/ STD. HOOK, TYP.
