Exterior metal composite material panel cladding is secured to structural steel framing at Level 02. Metal cladding support brackets attach to structural members to carry the exterior panel system. The slab edge and framing members align with the exterior cladding cavity.
LEVEL 02 18'-0" MP1 - EXTERIOR METAL COMPOSITE MATERIAL (MCM) PANEL METAL CLADDING SUPPORT METAL CLADDING SUPPORT
