Code-compliant hole drilling and notching limits for wood framing members include double top plates and sill plates. Notches are restricted to a maximum depth of D/2 at specific locations, requiring eight 16d nails on each side of the notch and a 10-gauge steel strap when notch depths exceed 1 inch. Drilled holes are limited to a maximum diameter of D/3, positioned within the middle third of the member depth with minimum edge distances. Shear wall top plates are left unnotched unless specifically detailed, and individual notches are spaced with maximum frequency limits.
5" 3" MAX 5" D/2 MAX D/3 2D MIN D/2 D/2 D NOTCH (8) 16d EA SIDE OF NOTCH (4 EA PL) NOTE: WHERE NOTCH IS GREATER THAN 1" PROVIDE 10GA STRAP W/ WIDTH SAME AS DBL TOP PL. TOP PL OF SHEARWALLS SHALL NOT BE NOTCHED UNLESS SPECIFICALLY DETAILED. DOUBLE TOP PL END OF SILL PL "B" 8" MAX @ SHEAR WALL 2D MIN D/2 D/2 D DRILLED HOLE NOTE: WHERE DEPTH OF NOTCH "B" IS GREATER THAN D/5 PROVIDE ANCHOR BOLT EA SIDE OF NOTCH AS PER END REQUIREMENT. NO MORE THAN ONE NOTCH IS PERMITTED IN EVERY 12'-0" @ SHEARWALL. D/3 DRILLED HOLE 5" MIN 9"MAX 5" MIN 9"MAX 5" MIN 9"MAX
