Steel framing connections are detailed for both a beam-to-tube column connection and a beam-to-beam connection. The steel beam web connects to the steel column or supporting steel beam using bolted clip angles. Standard edge distances and fastener spacings are maintained for the clip angles, with bolts installed through the webs and angles.
TYP. EA ANGLE 2 STEEL BEAM 3 SIDES BEAM TO BEAM CLIP ANGLE CONNECTION CLIP ANGLES STEEL BEAM 1 CLIP ANGLES BEAM TO TUBE COLUMN CLIP ANGLE CONNECTION 3 SIDES 3" 3" 1 1/2" MIN 1 1/2" 2" TYP. STEEL BEAM CLIP ANGLES 3 1/2" STEEL COLUMN STEEL BEAM 1 CLIP ANGLES 2 TYP. EA ANGLE
