A hollow structural section beam frames into a wide-flange beam supporting a concrete slab over metal deck, utilizing three-quarter-inch stiffener plates on each side welded with one-quarter-inch fillet welds typical on three sides. A metal stud kicker brace connects the structural steel to a built-up metal stud beam and ledger angle supporting the brick veneer. The assembly incorporates one-quarter-inch fillet welds for structural steel connections and maintains specified dimensional clearances of four inches minimum and three-quarters of an inch maximum.
3/4" STIFFENER PL EACH SIDE CONCRETE OVER METAL DECK REF. PLAN WF BEAM REF. PLAN TYP. METAL STUD KICKER BRICK VENEER REF. ARCH. HSS BEAM REF. PLAN LEDGER ANGLE BUILT-UP METAL STUD BEAM 1/4 1/4 TYP. TYP. 1/4 TYP. MAX. 3/4" 4" MIN. 1/4 (3) SIDES TYP. (3) SIDES
