A wall occupancy sensor with switch connects via a low voltage line labeled A to a plug load power pack and a standard power pack. The power packs feature multiple colored wire leads including white, black, orange, blue, violet, and gray for 120V or 277V line input and switched receptacle outputs.
LOCATION POWER PACK PLUG LOAD POWER PACK WALL OCCUPANCY SENSOR WITH SWITCH LOCATION ORANGE BLUE BLUE VIOLET GRAY B B B C C BLACK B WHITE B A A WHITE/NEUTRAL BLACK/LINE IN 120V ORANGE/LINE IN 277V BLUE/TO LINE IN 120V OR 277V BLUE/LINE OUT (RECEPTACLE) B B B B B
