An aircraft stop mark consists of a twelve-inch wide yellow line and a six-inch black border applied to asphalt paving. No black border is required when striping is placed on new asphalt. Twelve-inch tall yellow lettering with a black background is positioned at a variable distance from the main stripe. The layout specifies a one-foot dimension from the edge and includes reference text for aircraft tail positioning.
12" WIDE YELLOW LINE WITH 6" BLACK BORDER NO BLACK BORDER REQUIRED WHEN STRIPING ON NEW ASPHALT 73-8 VARIES 12" TALL LETTERING (YELLOW) BLACK BACKGROUND AS INDICATED (TYPICAL) LETTERING SHOWN FOR REFERENCE ONLY 1' 6' TO AIRCRAFT TAIL
