A concrete slab bears on a structural steel beam with studs welded to the top flange. The slab edge features a bent plate edge form and continuous reinforcing bars with 90-degree hooks sized to fit within the slab depth. A kicker brace is provided at the underside of the beam as specified per plan. Concrete cover is maintained at three-quarters of an inch.
T/STL CL BEAM PROVIDE HOOKED BARS AS REQUIRED PER NOTE 3 #4xCONT WHERE HOOKED BAR REQUIRED EDGE FORM PER SCHEDULE (12" UNO) A 2'-0" t NOTE 2 DIM "B" MIN 2" ROTATE 90° HOOK AS NEEDED TO FIT IN SLAB DEPTH 3/4" CLR PER PLAN SLAB THICKNESS CLR 3/4" CONC CONC PANEL. ORIENTATION PER PLAN KICKER WHERE OCCURS PER PLAN BENT PL STUD PER PLAN
