Headed reinforcement bars require a minimum clear cover of two bar diameters and a clear spacing between bars of at least four bar diameters. Designation tags specify quantity, bar size, headed bar designation, and spacing. The bearing area of the headed bar and bar thickness are detailed alongside the naming convention.
NOTES: 1. CLEAR COVER TO BAR SHALL BE 2 db MINIMUM, AND CLEAR SPACING BETWEEN H5 HEADED BARS SHALL BE 4db MINIMUM. t BAR HEAD BEARING AREA (4) #5 H5 @ 24 SIZE QUANTITY HEADED BAR DESIGNATION SPACING
