Concrete stair treads terminate directly against a six-inch shaft wall that also accommodates an elevator rail support post. Additional reinforcing information is referenced to typical concrete stair reinforcing details.
SECT STAIR TREADS NOTES: 1. SEE TYPICAL CONCRETE STAIR REINFORCING DETAIL FOR ADDITIONAL INFORMATION AND REINFORCEMENT. 6" SHAFT WALL OR ELEVATOR RAIL SUPPORT POST TREAD TERMINATES AT SHAFT WALL SECTION 3 TYP CONC STAIR SUPPORTING SHAFT WALL
