Concrete masonry unit non-load bearing walls feature bond beams reinforced with horizontal bars positioned about the center line of the wall. Type A incorporates a single reinforcing bar with standard half-inch minimum clearance. Type B accommodates two reinforcing bars requiring a one-inch minimum clearance where applicable. Vertical reinforcement is placed per the concrete masonry unit non-load bearing wall reinforcing schedule.
TYPE A TYPE B CL WALL CL WALL 1 1/2" 1" MIN CLR FOR (2) BARS, WHERE OCCURS 1" 1/2" MIN CLR, TYP VERT PER "CMU NON-LOAD BEARING WALL REINF SCHED" VERT PER "CMU NON-LOAD BEARING WALL REINF SCHED" BOND BEAM BOND BEAM
