An oversized outer track spans over an inner track in a cold-formed metal stud framing assembly. The configuration uses nested track profiles to accommodate specific structural movement or alignment tolerances.
METAL STUD FRAMING REF. ELEVATIONS OVER SIZED OUTER TRACK XXXTXXX-XX INNER TRACK XXXTXXX-XX
