A dowel laminated timber floor slab bears on a structural steel beam, featuring a maximum eight-foot cantilever condition. The dowel laminated timber designer provides an uplift-resistant connection between the timber floor slab and the steel beam where required to resist unbalanced live loads at the cantilever. An uplift connector may be required per the timber consultant notes. Additional information is referenced per the typical timber floor slab detail.
STL BM, TYP GRID CANT 8'-0" MAX SEE FOR ADDL INFO 20/S-G01 SEE PLAN DLT DESIGNER TO PROVIDE UPLIFT RESISTANT CONN BTWN DLT AND STL BM WHERE REQD TO RESIST UNBALANCED LIVE LOAD AT THE CANTILEVER. UPLIFT CONNECTOR MAY BE REQUD PER TIMBER CONSULTANT NOTES: 1. SEE "TYPICAL TIMBER FLOOR SLAB" FOR ADDITIONAL INFORMATION. GRID PER PLAN TOC
