A diagonal bracing connection within a cold-formed steel stud wall assembly utilizes a 16-gauge by 18-inch by 1-foot-6-inch steel gusset plate. The connection incorporates 16-gauge by 3-inch straps fastened with number 8 self-drilling metal screws at each stud, alongside 16-gauge by 2-inch straps spaced at 8 inches on center. Diagonal and vertical laps are secured with number 12 self-drilling metal screws adhering to specified fastener counts. An outline of backing framed into the wall is indicated along with fiber cement board attachments. General notes require a minimum spacing of 1 1/2 inches and a 1/2-inch minimum edge distance for all connections.
NOTES : 1. PROVIDE 1 1/2" MIN SPACING AND 1/2" MIN EDGE DISTANCE 10-#12 SMS AT HORIZONTAL LAP (1) GUSSET PL 16GAx18"x1'-6" STEEL STUD 10-#12 SMS AT VERTICAL LAP (1) #8 SMS @ 6" OC (1) 16GAx3" STRAP w/ 2-#8 SMS AT EA STUD 16GAx2" STRAP w/ #8 SMS @ 8" OC OUTLINE OF BLK'G FRAMED INTO WALL 14-#12 SMS AT DIAGONAL LAP (1) 9-#12 SMS AT FCB TO STUD w/ VERTICAL LAP NOTES : 1. PROVIDE 1 1/2" MIN SPACING AND 1/2" MIN EDGE DISTANCE 10 - #12 SMS (1) GUSSET PL. 16GAx18"x1'-6" STEEL STUD 10 - #12 SMS (1) 14 - #12 SMS (1) 16GAx3" STRAP w/ #8 SMS AT EA STUD 16GAx2" STRAP w/ #8 SMS @ 8" OC OUTLINE OF BLK'G FRAMED INTO WALL
