Drag beams and joists require a minimum length beyond walls and must extend onto adjacent walls when unspecified. Drag blocking uses straps specified per the structural plans with two lines of blocking nails. Beam hangers and inverted beam hangers are provided as typical unless noted otherwise, using Simpson HUCQ connectors for engineered lumber and Simpson HU connectors for conventional lumber.
10' MIN LENGTH BEYOND WALL. EXTEND ONTO ADJACENT WALL IF LENGTH NOT SPECIFIED DRAG DRAG BLOCKING WITH STRAP TYPE PER DRAG DRAG BEAM OR DRAG JOIST PER PLAN w/ (2) LINES OF BN AND STRAP TYPE PER A A A A BEAM HANGER INVERTED BEAM HANGER PROVIDE TYPICAL HANGER U.N.O. ENG LUMBER - SIMPSON "HUCQ" CONV LUMBER - SIMPSON "HU" 1 S925 1 S925
