Two-by wood studs are fastened with ten-penny nails at six inches on center to exterior plywood sheathing, matching architectural specifications. Five-eighths-inch threaded studs spaced at sixteen inches on center connect through double wood studs. A three-quarter-inch bearing plate is welded to a hollow structural section steel tube with a quarter-inch fillet weld. Two five-eighths-inch adhesive anchors embedded four inches secure the assembly.
10d @ 6" O.C. SHT'G PER ARCH. 5/8"$ THR'D STUD @ 16" O.C. - TYP. 2x STUD NOTE: DETAIL IS SIM. AT STUD ONE SIDE 2" 3" 2" 1/4" TYP. 1/4 (E) P.W. SHT'G (2) 5/8"$ ADHESIVE ANCHOR - EMBED 4" EQ EQ BRG / 3/4"
