Number four reinforcing bars are placed at four inches on center, typically, for both vertical and horizontal reinforcement within the concrete retaining wall. The corner junction utilizes looped ties and hooked rebar laps to maintain continuity through the ninety-degree turn. Additional wall sizing and bar schedules are coordinated with the primary retaining wall details.
