A concrete wall panel bears on a stepped footing at the stepped bottom condition. Typical vertical reinforcement consists of two number five bars at four feet zero inches typical length. Additional horizontal and vertical corner bars are detailed with maximum three inch dimensions at the step transition. Bottom bar placement refers to detail one on sheet SD point three, and footing interface refers to detail ten.
