Cold-formed steel sill track 600T150-43 frames into a vertical jamb stud, allowing a maximum one and a half inch clearance. The web of the sill track is bent and fastened to the jamb stud with two number ten screws at the connection. Infill studs frame between the sill track and sole track, secured with two number ten screws top and bottom. A reference callout directs to sheet five of detail S703 for further jamb connection requirements.
A A MAX. 1 1/2" JAMB STUD REF. SCHEDULE BEND WEB OF SILL TRACK AND FASTEN TO JAMB STUD w/ (2) #10 SCREWS (2) #10 SCREWS TOP AND BOTTOM OF STUDS TYP. SILL TRACK 600T150-43 INFILL STUDS REF. ELEVATION SOLE TRACK 600T150-43 REF. 5/S703 FOR JAMB CONNECTION
