An angle brace connects to a structural steel beam oriented perpendicularly or parallel, utilizing a quarter-inch thick by five-foot by five-foot weld plate at each brace location. The angle brace is secured to the weld plate with a three-sixteenth-inch fillet weld. The metal deck is omitted from the view for clarity.
3/16" ANGLE TO WELD PL 3/16" 3/16" 2+ 1 STEEL BEAM ANGLE BRACE WELD PL 1/4" X5'-0"X5'-0" AT EACH BRACE, TYP. 3/16" ANGLE TO WELD PL 3/16" 3/16" STEEL BEAM 2+ 1 ANGLE BRACE WELD PL 1/4" X5'-0"X5'-0" AT EACH BRACE, TYP. (SKEW FOR BRACE) PARALLEL TO BEAMS PERPENDICULAR TO BEAMS METAL DECK NOT SHOWN FOR CLARITY
