Twenty gauge galvanized vertical B-deck attaches to galvanized hollow structural section top and bottom girts with Hilti X-HSN 24 fasteners at each flute in a thirty-six over seven pattern. The girts are offset from the galvanized hollow structural section column as needed per architectural drawings. Additional galvanized hangers secure the assembly.
HANGERS GALVANIZED HSS COLUMN BEYOND GALVANIZED HSS BOTTOM GIRT - SEE PLAN GALVANIZED HSS TOP GIRT - SEE PLAN 20 GAGE GALVANIZED VERTICAL B-DECK. FASTEN TO GIRTS WITH HILTI X-HSN 24 FASTENERS AT EACH FLUTE (36/7 PATTERN) OFFSET GIRTS FROM COLUMN AS NEEDED - SEE ARCH. SCALE : NONE S231 13 DETAIL
