The assembly consists of reinforced concrete masonry unit lintels with standard and inverted bond beam configurations for eight-inch and twelve-inch walls. Horizontal reinforcing and vertical reinforcing are placed per schedule within grouted cells. Alternate stirrup caps are provided in the twelve-inch wall detail. An inverted bond beam is used at the contractor's option where the bottom face of the lintel is entirely concealed.
A 8" WALL B 12" WALL HORIZ REINF PER SCHED VERT REINF PER SCHED TYP CALL HORIZ REINF HORIZ REINF PER SCHED TYP CALL HORIZ REINF INVERTED BOND BEAM AT CONTRACTOR'S OPTION WHERE BOT FACE OF LINTEL IS ENTIRELY CONCEALED LINTEL UNIT TYP VERT REINF PER SCHED TYP CALL HORIZ REINF TYP CALL HORIZ REINF ALT STIRRUP CAP LINTEL DEPTH LINTEL DEPTH
