A concrete ramp slab connects to a seven-inch concrete wall panel using number four reinforcing bars measuring three feet long spaced at twenty-four inches on center. These dowels are secured into the wall panel using Hilti HIT-RE 500-V3 structural epoxy or an approved equal. Special inspection is required for the epoxy installation.
7" WALL PANEL SEE PLAN RAMP/CONC SLAB #4 x 3'-0" LONG @ 24"OC IN HILTI HIT-RE 500-V3 EPOXY (ESR-3814) OR EQUAL. (SPECIAL INSPECTION IS REQD)
